For many printers, numbering garments is a large part of their business. The Number Machine could be just what the printer ordered. The press is constructed from tubular steel, which forms a sturdy base. The way the press works is simple. You can print either one or two-color numbers from zero to 99. For two color numbers the press holds two screens with numbers from zero to nine pre-exposed onto the screen.
One screen is attached to the press in the standard clamshell fashion; this screen pivots up and down over the pallet and is controlled by gas shocks. The second screen attaches to the press in a horizontal fashion on nylon rollers. You can pull the second screen over the pallet while the first screen comes down in the standard clamshell method. Both screens are pre-registered and exposed at the factory.
The pallet is the standard wood with a laminate covering. It's attached to the press via a support arm on rollers. This allows the pallet to be rolled under the number you want to print.
The registration system on this press is done visually, but that doesn't mean "eyeballing". Along the entire length of the press is a grid for each numbering position. A guide on the pallet support arm lines up with the grid. The alignment depends on whether you're printing a single numeral, or the left or right numeral of a double-digit number. This system allows you to quickly locate the pallet in the correct position for the screen and number position you want to print.
It takes only minutes to get acquainted with its visual registration system. Once that was accomplished, we handily printed one and two-color numbers from 2" to 12" quickly and precisely.
In addition to the two ready-to-use screens that come with the press (you can chose the style of these) you can purchase additional screens with dozens of numbering styles and sizes. If you don't want to purchase the pre-exposed screens from Inline, you can buy just the film positive for any of Inline's available styles.
Floor Space: 5' deep x 8.5' wide
Reasons to Buy Our In-Line Numbering Machine
- Designed for Production Numbering Applications
- Minimal Floor Space Required
- Fast Color Changes - Easy Clean-Up
- Many Optional Features Available
- Affordable Pricing
Silk Screen Numbering Machine Packages
Total Two Color Numbering Machine Package
716-800-1-EA
Eight Screens (Exposed w/ Choice of Lettering Style (2"-12")
4 Platens: 1 large, 1 adult, 1 youth, 1 sleeve, 9 squeegees
Quartz Numbering Flash Unit
716-800-8-EA
(Very Popular - a must buy for 2-Color Numbering)
120 Volts (20 amps) - Attaches to the press, slides.
Two Color Numbering Machine Two Screens
716-800-4-EA
(Exposed w/ Choice of Lettering Style)
(Standard stencil images: 2", 3", 8")
3 Platens: 1 adult, 1 youth, 1 sleeve, 4 squeegees
Two Color Numbering Machine Four Screens
716-800-3-EA
(Exposed w/ Choice of Lettering Style)
3 Platens: 1 adult, 1 youth, 1 sleeve, 4 squeegees
Two Color Numbering Machine Six Screens
716-800-2-EA
(Exposed w/ Choice of Style)
3 Platens: 1 adult, 1 youth, 1 sleeve, 4 squeegees
One Color Numbering Machine
One Screen (Exposed w/ Choice of Style)
3 Platens: 1 adult, 1 youth, 1 sleeve, 2 squeegees
